22kva Brushless Alternator For Specially Refrigerated Car

22kva Brushless Alternator For Specially Refrigerated Car

22kva Brushless  Alternator  For  Specially Refrigerated Car

পণ্যের বিবরণ:

Place of Origin: Wuxi,China
পরিচিতিমুলক নাম: WERNA
সাক্ষ্যদান: CE,ISO9001,SASO
Model Number: WR184EC

প্রদান:

Minimum Order Quantity: 5 pcs
মূল্য: negotiation
Packaging Details: Plywood
Delivery Time: 15 days
Payment Terms: T/T
Supply Ability: 1000 units/month
এখন যোগাযোগ
বিস্তারিত পণ্যের বর্ণনা
দ্রুততা: 1500 আরপিএম বা 1800 আরপিএম অন্তরণ শ্রেণি: এইচ
পাটা: ২ বছর আউটপুট টাইপ: এসি থ্রি ফেজ এবং 3 ফেজ ডিজেল জেনারেটর
রঙ: ঐচ্ছিক টেলিগ্রাম: 100% তামা তার



22kva Brushless  Alternator  For  Specially Refrigerated Car




Quick Detail:

Name

Alternator

Brand Name

WERNA

Color

According to the international standard color card

Feature



AC brushless synchronous excitation alternator



Power

          22 kva

Certificate

CE,ISO9001,SASO




Specifications:

Model

WR184EC

manufacturer

Wuxi City ,Jiangsu Prov ,China making alternators

Output Type

AC Single Phase diesel generator

Terminal

12 / 6 Wire

Rated Voltage

460 V

Frequency

60 HZ

Speed

1800 RPM

Mounting dimensions

Stamford Type

Winding Pitch

2 / 3 pitch

Excitation

Brushless, self-excited, synchronous

Insulation Class

H



Description:
Frequency And Voltage
50Hz or 60Hz as per customer’s request. Voltage from 380 ~ 690V, 190V~345V, 220~400V, serial star, parralle star and serial delta connection are available, All three-phase generators are 12-lead reconnectable, providing voltage and phase flexibility.
Insulation and Protection
Insulation: H, Protection: IP22
Voltage Regulators
The model we use including: MX321, MX341, AS440, SX440, SX460, etc.
Winding
All generator stators are wound to 2/3 pitch.
The quality management system of our factory
A set of integrated quality management system,there are standard imported checking rules of every component.All the suppliers should be selected and checked strictly by our factory,all the materials should be appointed specially after the strict selection by our factory.

FAQ

1. Q: What is the lead time?



       A: 15 days after receiving your L/C or TT deposit.

 2. Q: Is it all right to make customer's own brand name?

       A: We can be your OEM manufacture with your authorization of brand.

 3. Q: Where is your Loading Port?

       A: Shanghai, China Port.

 4. Q: What are your payment terms?

       A: 30% deposit and balance T/T against copy of Bill of Lading or L/C at sight.

  5. Q: What is your company's available production capacity?

       A: 10000  pieces against your orders.
